Discover Four-State RFID Wire Seal

The Four State RFID Wire Seal is a high-security RFID-enabled seal with a 16-meter reading range, tamper-proof design, and customizable features, including logo, barcode, and QR code printing. Equipped with a 165mAh battery and multiple operation states, it ensures reliable tracking and anti-theft protection for secure asset management.

Four-State RFID Wire E-Seal - Technical Specification:

Characteristics:

The 4State RFID Wire Seal is a tamper-proof, waterproof, on-metal-compatible security tag with temperature and detection sensors, 4-state tracking, and long-range reading via Battery-Assisted Passive mode.

Features:

Waterproof (IP66): Rated for dust and water resistance, suitable for outdoor and harsh environments.

Tamper-Proof: Designed to detect any tampering attempts, securing assets with high reliability.

On-Metal Use: Compatible with metallic surfaces without signal interference, broadening its usability.

Temperature & Detection Sensors: Equipped with sensors to monitor temperature and detect tampering, enhancing security.

Memory:

TID/UID (112-bit): Stores a unique identifier for the tag, crucial for distinguishing each tag from others.

EPC (192-bit): An Electronic Product Code memory for encoding product details, allowing easy identification in asset management.

User File (512-bit): Provides space for custom data storage, useful for specific asset tracking requirements.

Reserve (112-bit): Reserved memory for additional, customizable security features or future updates.

Chip & Protocol:

Chip: Uses the CAB1/VBL7-NC chip, known for efficient, secure data processing.

Protocol: Operates on ISO18000-6C GEN2 V2, a widely compatible and standardized protocol for UHF RFID, ensuring interoperability across various RFID readers.

Compatibility:

Works with specialized readers (BU01READER or PU01 PDA) for accurate tamper detection and to access all security states.

Displays security states (FAKE, REAL, UNLOCKED, LOCKED, and TAMPERED), with special encryption encoding for secure, online, and offline asset tracking and management.

Dimensions:

Tag Size: Measures 341mm in length, 50mm in width, and 19mm in height, making it compact yet robust.

Antenna Size: The antenna within the tag measures 58mm x 37mm, optimized for reliable signal transmission over extended distances.

Battery:

Embedded with a 165mAh coin battery, which extends the tag’s reading performance (via Battery-Assisted Passive mode) for up to 12 months after locking, ensuring a long operational life.

Housing:

Made from durable ABS plastic with a galvanized steel wire cable (4mm diameter), providing rugged protection for the RFID components against environmental wear and tampering.

Frequency:

Operates in the 865-868 MHz range, the standard UHF RFID frequency, ideal for long-range reading while minimizing interference.

Reading Range:

The tag can be read from up to 16 meters (1600 cm) depending on the reader's power, enabling efficient tracking over long distances.

Installation:

Offers versatile options: can be tied, tightened, inserted, or locked, allowing flexibility in securing different assets.

Four-State RFID Wire Seal

The Four State RFID Wire Seal is a high-security RFID tag designed to provide reliable, long-range asset tracking and tamper detection. Featuring a 4-state tracking system (FAKE, REAL, LOCKED, TAMPERED), it ensures accurate real-time monitoring of asset status. With a reading range of up to 16 meters and a built-in 165mAh battery supporting up to 12 months of operation, the seal is ideal for secure, remote asset management. It is waterproof (IP66) and designed for use on metal surfaces, making it suitable for harsh environments. The seal also includes temperature and detection sensors, offering enhanced security and environmental monitoring. Easy to install with versatile attachment options, the 4State RFID Wire Seal is perfect for industries that require robust, tamper-proof solutions for asset protection and tracking.

Get in Touch Today

Benefits Of Four-State RFID Wire Seal:

Enhanced Security: The tamper-proof design ensures that any unauthorized access or tampering with the asset is immediately detected, helping to prevent theft or loss.

Real-Time Tracking: With long-range RFID technology (up to 16 meters), the seal enables efficient remote monitoring and real-time tracking of assets, reducing the need for manual checks.

4-State Tracking System: The ability to track the seal’s status in four distinct states (FAKE, REAL, LOCKED, TAMPERED) provides clear and precise information on the security of the asset, improving asset management and reducing the risk of undetected tampering.

Durability and Weather Resistance: The IP66 waterproof rating ensures the seal remains operational even in harsh environments, including outdoor and industrial settings, where moisture, dust, or dirt could interfere with traditional security solutions.

On-Metal Compatibility:Unlike standard RFID tags, this seal can be used on metal surfaces without loss of signal strength, expanding its applicability to various industries, such as logistics, transportation, and manufacturing.

Cost-Efficiency: The 165mAh coin battery supports up to 12 months of use from a single charge, reducing maintenance costs and the frequency of battery replacements.

Simple Installation: The versatile installation options (tie, tighten, insert, or lock) make it easy to secure items, providing flexibility for different asset protection needs.

Environmental Monitoring: Integrated temperature and detection sensors help monitor the conditions around the sealed asset, ensuring it is kept within the desired parameters, which is particularly valuable for sensitive goods.

Customizable: With options for logo, barcode, QR code, and serial number printing, the 4State RFID Wire Seal can be personalized for specific branding and inventory management needs.

Easy Integration: The seal works with a wide range of RFID readers, making it easy to integrate into existing asset management systems without the need for specialized infrastructure.

Secure, Track, Protect – The Ultimate RFID Solution for Every Asset.

"Secure, Track, Protect – The Ultimate RFID Solution for Every Asset" highlights the core benefits of the 4State RFID Wire Seal. It emphasizes the product's ability to provide robust security, reliable tracking, and protection for assets in various industries, ensuring their safety and integrity.
